Recently, Pope Francis made headlines when he called unrestrained capitalism the “dung of the devil.*” I’m betting he’s never been a network engineer dealing with negotiation issues.** Problems at the physical layer always seem to be the most painful, mostly because you think, “Dammit, I should have known better!”
These thoughts come after the third in a series of attempts to insert a Vendor’s network packet broker bypass module inline at my $dayjob. Vendor requires and only supports manual configuration of the GigE LX fiber ports, but we couldn’t get this to work. It was infuriating, because we seemed to have link, but the dB loss was too high.
I should mention that in most of my previous jobs, the network team always managed the perimeter router. But not in this shop. Unbeknownst to me, the demarcation point, a port on a router, was set to auto-negotiate. This wasn’t identified in the diagram and was only discovered after lots of yelling by a cast of thousands, including multiple representatives from the Vendor, in a server room late at night. This issue was finally resolved by opening a case with the service provider and requesting that they hard set the uplink port on the managed router.
The situation was infuriating. I woke up at 5:00 AM the next morning with a bad case of nerd-rage. I needed to find a target for my anger, so I went to Google to help me direct this justified (so I thought) apoplexy. I started reading through the IEEE standards on Ethernet and 1000BASE-X, even finding an “interpretation” document. This just made me more irate.
The Auto-Negotiation algorithm of Clause 28, while the preferred method for the determination of half or full duplex operation, is not currently defined for fiber MAUs.
Manual configuration, while not recommended for copper-based MAUs, is the only practical choice for fiber implementations. Connecting incompatible DTE/MAU combinations such as a full duplex mode DTE to a half duplex mode MAU, or a full duplex mode station (DTE and MAU) to a half duplex network, can lead to severe network performance degradation, increased collisions, late collisions, CRC errors, and undetected data corruption.
Point – Vendor
188.8.131.52 User Configuration with Auto-Negotiation
Rather than disabling Auto-Negotiation, the following behavior is suggested in order to improve interoperability with other Auto-Negotiation devices. When a device is configured for one specific mode of operation (e.g. 1000BASE-X Full Duplex), it is recommended to continue using Auto-Negotiation but only advertise the specifically selected ability or abilities. This can be done by the Management agent only setting the bits in the advertisement registers that correspond to the selected abilities.
Point – Mrs. Y. The Vendor doesn’t support this option.
Interpretation for IEEE std 802.3-2002 #1-11/02 (1000BASE-X Auto-negotiation)
The standard clearly states in the second paragraph of subclause 184.108.40.206.1 Control register (Register 0), “When manual configuration is in effect at a local device, manual configuration should also be effected for the link partner to ensure predictable configuration.”
Hence, if this recommendation is not followed and a link has manual configuration in effect at a local device but not at the link partner, or the reverse, the resultant link configuration can not be predicted.
Point – Vendor
Final Decision: I will direct my righteous indignation at the IEEE. I spent over two hours going through reams of documentation to find this information and I’m still confused by which is the “best practice.” Is it any wonder that vendors and network professionals still argue about the standards?
*Devil Dung would be a great name for a punk rock band.
** And please don’t flame me over referencing Pope Francis. He seems like a cool guy with a good sense of humor. I don’t think he’d mind.
